Since its inception in 2014 the Jamis Renegade has been defining versatility in modern adventure bikes. It’s not easy improving on something that’s capable of, well, just about everything, but our NEW Renegade platform is simply exceptional. We’ve succeeded in preserving the all-important DNA of our original Renegade while also adding more tire clearance, adjustability, and compliance.
Read on to understand Jamis’ approach to adventure frame design and how it keeps the Renegade’s superior ride quality consistent regardless of tire choice and frame size, on-road or off.
| RENEGADE | C4 |
|---|---|
| Frame | Renegade Dyad Plus T700/FRP monocoque carbon fiber frame, Near Net molding process, 12×142 thru-axle, SST tubing diameters, 1.5 – 1 1/8” head tube, EVO386 carbon BB shell, internal cable routing compatible for both Di2 wires or traditional cables and internal dropper post, flat mount disc brakes and exposed fender mount eyelets, carbon drop outs, FD mount and replaceable threaded UDH hanger and TA mount, clearance for 45-50c tires |
| Fork | Renegade monocoque carbon composite fiber fork, flip-chip with 50/55mm offset, 12mm thru-axle, carbon dropouts, tapered steerer with 1.5” hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender mounts and water bottle eyelets |
| Headset | Ritchey Comp Drop-In, sealed bearing with nylon upper compression ring, 1.5 – 1 1/8” |
| Wheels | Boyd CCC Tubeless wheelset, i25, 28/32H, Boyd Quest centerlock ABEC 3 cartridge sealed bearing hubs, Pillar Wing 20 spokes, HG Driver, Wingnut tubeless valves, front 12mm/rear 12×142 thru-axles with Switch Lever. Min tire size 30mm, Max tire Pressure 70psi/4.8bar |
| Tires | WTB Raddler Tubeless, 700 x 44c, Dual DNA Compound, Aramid bead |
| Derailleurs | SRAM Apex XPLR eTap AXS |
| Shift levers | SRAM Apex eTap AXS HRD, 12-speed |
| Chain | SRAM Apex |
| Cassette | SRAM PG 1231 XPLR 12-speed, 11-44T |
| Crankset | SRAM Apex Wide 40T, 165mm (48), 170mm (51), 172.5mm (54/56), 175mm (58/61) |
| BB Set | SRAM DUB BB386 |
| Pedals | N/A |
| Brakeset | SRAM Apex hydraulic disc brakes, Centerlock Centerline 160mm rotors with SRAM Apex eTap AXS HRD levers |
| Handlebar | Ritchey Baquiano Comp, 6061 aluminum, 73 reach, 118 ergonomic drop with 12° flare, 31.8 x 420 (48-51) 440mm (54-56), 460mm (56-61) |
| Stem | Ritchey 4-AXIS Stem 6°x60mm (48-51), 70mm (54-56), 80mm (58/61) |
| Tape | Velo EVA gel with gel inserts |
| Seat Post | Jamis carbon fiber micro-adjust, 27.2 x 330mm, 0mm offset with Jamis 7075-AL CNC aluminum 1-bolt seat post clamp |
| Saddle | Selle Royal SRX Gravel Saddle with relief hole and MG rails |
| Sizes | 48, 51, 54, 56, 58, 61cm |
| Color | Thunder Grey |
| Weight | 19.9 lbs |
